| TUNER SECTION |
| Frequency Bands |
|
| FM: (MHz) 0.05 MHz steps |
87.5 to 108 |
| MW: (kHz) 9 kHz steps |
531 to 1,602 |
| LW: (kHz) 3 kHz steps |
153 to 279 |
| FM Usable Sensitivity (dBf) |
11 |
| FM 50 dB Quieting Sensitivity (dBf) |
17 |
| FM Alternate Channel Selectivity (dBf) |
75 |
| FM Stereo Separation @1 kHz (dB) |
35 |
| FM Stereo Freq. Resp. @ ±3 dB (Hz) |
30 to 15,000 |
| CD SECTION |
| S/N Ratio (dB) |
85 |
| Frequency Response (Hz) |
10 to 20,000 |
| Dynamic Range (dB) |
87 |
| Harmonic Distortion (%) |
0.01 |
| AUDIO SECTION |
| Power Output (DIN45324, +B = 14.4 V) |
4 × 25 W |
| GENERAL |
| Dimensions (W × H × D), mm |
178 × 50 × 152 |
| Weight (kg) |
1.1 |
| Power Consumption: less than |
15 A |
| Speaker Impedance |
4Ω (4 Ω to 8 Ω allowable) |
