| TUNER SECTION |
|
| Frequency Bands |
|
| FM: (MHz) 0.2 MHz steps |
87.9 to 107.9 |
| AM: (kHz) 10 kHz steps |
530 to 1,710 |
| FM Usable Sensitivity (dBf) |
9 |
| FM 50 dB Quieting Sensitivity (dBf) |
15 |
| FM Alternate Channel Selectivity (dBf) |
70 |
| FM Stereo Separation @1 kHz (dB) |
35 |
| FM Stereo Freq. Resp. @ 3 dB (Hz) |
30 to 15,000 |
| CD SECTION |
|
| Wow/Flutter (WRMS) |
Below measurable limit |
| S/N Ratio (dB) |
100 |
| Frequency Response (Hz) |
10 to 20,000 |
| Dynamic Range (dB) |
93 |
| Harmonic Distortion (%) |
0.03 |
| AUDIO SECTION |
|
| Maximum Power Output |
50W × 4 |
| GENERAL |
|
| Dimensions (W × H × D), mm |
178 × 50 × 155 |
| Power Consumption: less than |
15A |
| Speaker Impedance |
4 (4 to 8 allowable) |
